Steel-wire reinforced PE grid, GSZ 30–150 kN/m, built for heavy loads and marine works.
High-strength steel wires encased in textured PE strips are welded into grids with yield elongation ≤3%. Superior corrosion resistance makes it the answer for seawalls, mining and high retaining walls where traditional grids fail.
| Item | Value |
|---|---|
| Models | GSZ30-30 – GSZ150-150 |
| Tensile yield force | 30 – 150 kN/m (MD & CMD) |
| Yield elongation | ≤ 3% |
| Force at 2% elongation | 27 – 127 kN/m |
| Roll width | up to 6 m |
Custom specifications available on request. Ask for the full technical datasheet.
Send us your project details and get a quotation with technical datasheets within 24 hours.
