Composite Geomembrane

Nonwoven geotextile bonded with HDPE membrane — barrier plus protection in one roll.

Composite geomembrane laminates HDPE film with nonwoven geotextile on one or both sides, combining impermeability with puncture protection and improved interface friction. Widely used for dam faces, canals, cofferdams, tunnels and roadbed treatment in saline soils.

Send Inquiry Chat on WhatsApp

Features

One-cloth-one-membrane or two-cloth-one-membrane constructions
Higher puncture resistance than plain geomembrane
Improved friction angle for safe placement on slopes
Custom widths and weights to project specification

Applications

Impervious blankets and cut-offs for dams
Channels, liquid pools and waste storage
Anti-seepage lining of subways, basements and tunnels
Roadbed treatment in saline and soft soils

Key Specifications

Item	Value
Construction	1 cloth + 1 membrane / 2 cloth + 1 membrane
Roll width	1 – 6 m
Roll length	50 – 100 m (customizable)
Membrane	HDPE, 0.2 – 1.5 mm
Geotextile	Needle-punched nonwoven, 100 – 600 g/m²

Custom specifications available on request. Ask for the full technical datasheet.
